Use as Rain Drain, D-Box, or Drop Box; allows for all configurations
Use as a rain drain for gutters, driveways & sub surface drainage
Use as a distribution box or drop box for onsite septic systems
Accepts 2'', 3'', 4'' and corrugated pipe
Use with solid cover or grate, your choice, no additional cost
Four stabilizing feet with every box
Installation Instructions:
1. Carefully cut out required opening in the box with a knife. 2. Install seal from INSIDE the box. 3. Screw on the nut from OUTSIDE the box. 4. Tighten to provide a watertight seal. 5. Remove the correct size tear out on the seal. TEAR OUT- DO NOT CUT OUT. 6. Slide the pipe into the seal. 7. Snap the stabilizing feet into the sockets at the base of the box. (12" only)
Special Instructions for Installing 4" Corrugated Pipe Only:
1. Remove the 4" TEAR OUT on the seal. TEAR OUT DO NOT CUT OUT. 2. Carefully cut between raised ribs on back of seal in all 4 places. 3. Push corrugated pipe into seal.
